A Stone Burier for Hydraulic Loader
This soil preparer and burier is ideally suited for hydraulic compact loaders with Bobcat hitching plate
It may also be adaptable to your carrier by you: delivered without coupling plate, without hoses, without couplers: (RDH 70 ADAPT)
It allows the development and/or renovation of green spaces by preparing the seedbed before sodding. The machine is multi-purpose, it allows milling, burying (stones, rubbish, grass, etc.), levelling, mixing and rolling of the surface. The use is done directly or on ground previously decompacted in depth and cleared of large stones.
| PTO shaft rotation speed | 540 RPM |
|---|---|
| Required Power | 70-90 HP |
| Transmission | Hydraulic Motor |
| Working Width | 1500mm |
| Depth control | Screw Jacks System |
| Number of blades | 32, Mechanical |
| Outside rotor diameter | 740mm |
| Working Depth | 140mm |
| Overall Width | 1850mm |
| Number of grate fingers | Mechanical |
| Number of screening rods | 49 |
| Weight | 580kg |
| Transport dimension (mm) | 850 mm x 1650 mm x 1700 mm |
| Mount | Quick attach plate |
